| Models |
 |
 |
 |
 |
 |
 |
 |
| Rotation |
Clockwise and ANTICLOCKWISE |
Clockwise and ANTICLOCKWISE |
Clockwise and ANTICLOCKWISE |
Clockwise |
Clockwise |
Clockwise |
Clockwise |
| Engine Capacity Litre/ Cylinders |
0.5 |
1.1 |
1.3 |
1.4 |
1.5 |
2 |
1.5 |
| Max no of Cylinders |
4 |
6 |
6 |
6 |
6 |
6 |
8 |
| Peak Torque Output Nm (ft lb) |
91 (47) |
115 (85) |
120 (89) |
124 (91.5) |
126 (93) |
140 (104) |
147 (109) |
| Maximum Output Turns |
2.25 |
2.75 |
2.75 |
3 |
3.5 |
3.5 |
3.5 |
| Cold Starting to 0o C |
Starting aid might be required |
Starting aid might be required |
Starting aid might be required |
Starting aid might be required |
Starting aid might be required |
Starting aid might be required |
Starting aid might be required |
| Max Winding Load Torque Nm (ft lb) |
60 (40) |
64 (47) |
81 (60) |
85 (63) |
90 (66) |
94 (69) |
94 (69) |
| Turns to Fully Wind (Approximate) |
10 |
11.5 |
11.5 |
14 |
14.5 |
16.5 |
17 |
| Pinion |
11-13 teeth 6/8, 8/10 & 10/12 Fellow stub |
11-13 teeth Module 3 BE CUSTOMISED |
11-15 teeth Module 2.5 |
PINION CAN ALSO |
| Mounting Flange Type |
SAE1, SAE 2 & 3, SAE 4 |
FLANGES CAN ALSO BE CUSTOMISED |
| Standard Equipment |
WINDING HANDLE, HANDBOOK AND SET UP GAUGE |
| Optional Features |
ELECTRONIC CUT OFF SAFETY SWITCH FOR DUAL STARTING SYSTEM/ SPECIAL WINDING HANDLE |
| Weight (Kg) *(Weight slightly differs depending on different models) |
14.2 |
16.31 |
17.48 |
18.6 |
22.32 |
24.17 |
25.88 |
| Dimensions LWH cm *(Dimensions differs depending on different models) |
280/ 120/ 155 |
285/ 125/ 155 |
290/ 125/ 160 |
318/ 125/ 160 |
335/ 143/ 195 |
340/ 150/ 200 |
355/ 155/ 210 |
